| Mobile |
5G Sub-6 GHz SA, NSA 2.4, 3.4Gbps DL (4x4 MIMO) 900, 550Mbps UL (2x2 MIMO); 4G LTE: DL Cat 19 1.6Gbps (4x4 MIMO), UL Cat 18 200Mbps |
| CPU |
Mediatek, Dual Cores, 880 Mhz, MIPS1004Kc |
| RAM |
256 MB DDR3 |
| Storage |
16 MB serial NOR flash, 256 MB serial NAND flash |
| Powering options |
M12 A code 4-pin male, 9 - 50 VDC |
| TPM |
Identification and authentication module, TPM 2.0 standard |
| SIM |
2 x SIM slots (Mini SIM - 2FF), 1.8 V/3 V |
| eSIM |
Consumer type eSIM, profile download and removal operations, up to 7 eSIM profiles; does not include data plans |
| Antenna connectors |
4 x SMA for Mobile, 2 x RP-SMA for Wi-Fi, 1 x SMA for GNSS |
| Ethernet |
4 x M12 X code 8-pin female ports, 10/100/1000 Mbps |
| Wi-Fi |
802.11b/g/n/ac Wave 2 (Wi-Fi 5) with data transmission rates up to 867 Mbps (Dual Band, MU-MIMO) |
| GNSS |
GPS, GLONASS, BeiDou, Galileo and QZSS |
| Inputs/Outputs |
2 x Inputs for Ignition Detection and Low Battery |
| Grounding |
1 x Grounding screw |
| Status LEDs |
4 x WAN type, 3 x Mobile connection type, 3 x Mobile connection strength, 6 x LAN status, 2 x WAN status, 1 x Power, 2 x 2.4G and 5G Wi-Fi |
| Operating temperature |
-40 °C to 75 °C |
| Housing |
Anodized aluminum housing and panels |
| Dimensions (W x H x D) |
167 x 46.2 x 112.4 mm |
| Weight |
550 g |
