| CPU |
Broadcom BCM2712 2.4GHz quad-core 64-bit Arm Cortex-A76 |
| GPU |
VideoCore VII GPU, supporting OpenGL ES 3.1, Vulkan 1.2 |
| RAM |
LPDDR4X-4267 SDRAM (มีรุ่น 4GB และ 8GB) |
| การแสดงผล |
2 x 4Kp60 HDMI® display output with HDR support |
| Video Decode |
4Kp60 HEVC decoder |
| Wi-Fi |
Dual-band 802.11ac Wi-Fi® |
| Bluetooth |
Bluetooth 5.0 / Bluetooth Low Energy (BLE) |
| Storage |
microSD card slot, with support for high-speed SDR104 mode |
| USB |
2 × USB 3.0 ports, 2 × USB 2.0 ports |
| Ethernet |
Gigabit Ethernet, with PoE+ support (ต้องใช้ PoE+ HAT เพิ่มเติม) |
| MIPI |
2 × 4-lane MIPI camera/display transceivers |
| PCIe |
PCIe 2.0 x1 interface (ต้องใช้ M.2 HAT หรืออะแดปเตอร์อื่นเพิ่มเติม) |
| Power |
5V/5A DC via USB-C, with Power Delivery support |
| GPIO |
Standard 40-pin header |
| คุณสมบัติใหม่ |
Real-time clock (RTC), Power button |
