Shelly 1 Gen4

คำอธิบาย

Shelly 1 Gen4 Wi-Fi 6 • Gen4

Smart Relay Switch with Wi-Fi 6 & Temperature Sensor

Shelly 1 Gen4 เป็น Smart Relay Switch รุ่นล่าสุดพร้อม Wi-Fi 6 (802.11ax), Built-in Temperature Sensor, Scripting Support และมี 3 รุ่นให้เลือก: AC (110-240V), DC (12-48V) และ 12V (5-12V) รองรับ 1 Channel Relay สูงสุด 8A/10A เหมาะสำหรับ Smart Home Automation, Lighting Control, Appliance Control และ DIY Projects พร้อมรองรับ Shelly Cloud, MQTT, CoAP และ Smart Home Platforms

🏡 จุดเด่นและการใช้งาน

💡 Smart Lighting Control • 🏠 Appliance Automation • 🚪 Garage Door Control • 🔥 Water Heater Control • 💨 Fan Control • 💧 Irrigation Systems • 🛠️ DIY Home Automation • 📱 Remote Control via App • 🌡️ Temperature Monitoring • 🔄 Automation & Scheduling

📸 Product Images

Shelly 1 Gen4 AC Model
Shelly 1 Gen4 AC (110-240V)
Shelly 1 Gen4 DC Model
Shelly 1 Gen4 DC (12-48V)
Shelly 1 Gen4 12V Model
Shelly 1 Gen4 12V (5-12V)

⚡ Available Models

AC Model

Shelly 1 Gen4 AC

110-240V AC, 50/60Hz

  • Max Load: 8A @ 240V AC
  • Max Load: 10A @ 110V AC
  • Power: 1840W @ 230V / 1100W @ 110V
  • Input Voltage: 110-240V AC
  • Ideal for: Lights, Fans, Appliances
DC Model

Shelly 1 Gen4 DC

12-48V DC

  • Max Load: 10A @ 12-48V DC
  • Power: 120W @ 12V / 480W @ 48V
  • Input Voltage: 12-48V DC
  • Ideal for: LED Strips, DC Motors, Solar
12V Model

Shelly 1 Gen4 12V

5-12V DC

  • Max Load: 10A @ 5-12V DC
  • Power: 50W @ 5V / 120W @ 12V
  • Input Voltage: 5-12V DC
  • Ideal for: Low Voltage LED, USB Devices

📦 HARDWARE FEATURES

📶

Wi-Fi 6 Connectivity

  • Wi-Fi 6 (802.11ax)
  • 2.4 GHz Band
  • Improved Speed & Range
  • Better Multi-Device Support
  • Lower Power Consumption
🔌

Relay Control

  • 1 Channel Relay Output
  • AC: 8A @ 240V / 10A @ 110V
  • DC: 10A @ 12-48V
  • 12V: 10A @ 5-12V
  • Manual Switch Input
  • Momentary/Toggle Mode
🌡️

Temperature Sensor

  • Built-in Temperature Monitoring
  • Overheating Protection
  • Temperature-based Automation
  • Real-time Monitoring
  • Alert Notifications
🔄

Scripting & Automation

  • JavaScript Scripting Support
  • Custom Automation Logic
  • Conditional Actions
  • Timers & Schedules
  • Scene Control
📱

Control Options

  • Shelly Cloud App (iOS/Android)
  • Web Interface
  • Physical Switch Input
  • Voice Control (Alexa, Google)
  • REST API
  • MQTT Protocol
🏠

Smart Home Integration

  • Amazon Alexa
  • Google Home
  • Home Assistant
  • Samsung SmartThings
  • Apple HomeKit (via bridge)
  • Hubitat
🔒

Security & Protocols

  • MQTT Support
  • CoAP Protocol
  • WebSocket
  • HTTP/HTTPS
  • Secure Cloud Connection
  • Local Control Available
📏

Compact Design

  • Ultra-Compact Size
  • Fits Behind Switch
  • Easy Installation
  • DIN Rail Mountable
  • Operating Temp: -20°C to +40°C

Technical Specifications Comparison

Specification AC Model DC Model 12V Model
Input Voltage 110-240V AC, 50/60Hz 12-48V DC 5-12V DC
Max Load Current 8A @ 240V / 10A @ 110V 10A @ 12-48V 10A @ 5-12V
Max Power 1840W @ 230V / 1100W @ 110V 120W @ 12V / 480W @ 48V 50W @ 5V / 120W @ 12V
Wi-Fi Wi-Fi 6 (802.11ax), 2.4 GHz
Relay Channels 1 Channel
Temperature Sensor Built-in
Scripting JavaScript Support
Switch Input 1x Input (Momentary/Toggle)
Operating Temperature -20°C to +40°C
Protocols MQTT, CoAP, WebSocket, HTTP/HTTPS
Cloud Support Shelly Cloud
Voice Control Alexa, Google Assistant

💻 SOFTWARE FEATURES

Control & Management

Mobile App Shelly Cloud App (iOS & Android) - Remote control, monitoring, scheduling, scenes
Web Interface Local web interface for configuration and control without cloud dependency
Voice Control Amazon Alexa, Google Assistant integration for hands-free control
API Access REST API, MQTT, CoAP, WebSocket for custom integrations and automation

Automation Features

Scripting JavaScript scripting engine for custom automation logic and conditional actions
Schedules Time-based automation with daily, weekly schedules and sunrise/sunset triggers
Scenes Create multi-device scenes and automation workflows
Webhooks HTTP webhooks for integration with external services and IFTTT
Temperature Actions Automation based on built-in temperature sensor readings

Smart Home Integration

Amazon Alexa Native integration for voice control and routines
Google Home Native integration for voice control and automation
Home Assistant Full integration via MQTT or native Shelly integration
Samsung SmartThings Integration via custom device handlers
Apple HomeKit Integration via Homebridge or Home Assistant bridge
Hubitat Native integration for local control

Network & Security

Wi-Fi 6 802.11ax 2.4 GHz with improved speed, range, and multi-device performance
Local Control Works without internet connection via local network
Cloud Control Optional Shelly Cloud for remote access and control from anywhere
MQTT MQTT protocol support for local automation and integration
Firmware Updates OTA (Over-The-Air) firmware updates via app or web interface

Monitoring & Notifications

Temperature Monitoring Real-time temperature monitoring with historical data and graphs
Status Monitoring Real-time relay status, connection status, and device health
Push Notifications Mobile app notifications for status changes, alerts, and automation triggers
Email Alerts Email notifications for critical events and temperature alerts
Activity Log Detailed activity log with timestamps for all device actions

🎯 Use Cases & Applications

Smart Lighting Control lights, lamps, and lighting fixtures with scheduling and automation
Appliance Control Automate coffee makers, heaters, fans, and other appliances
Garage Door Smart garage door control with status monitoring and notifications
Water Heater Schedule water heater operation with temperature monitoring
Irrigation Automate garden irrigation systems with scheduling
LED Strips Control DC LED strips and low voltage lighting (DC/12V models)
DIY Projects Custom home automation projects with scripting support
Energy Management Schedule high-power devices during off-peak hours
