TRB246

คำอธิบาย

Teltonika TRB246 4G LTE Cat 4 + GNSS

Industrial 4G LTE Gateway with GNSS & Dual SIM

TRB246 เป็น Industrial 4G LTE Cat 4 Gateway พร้อม GNSS (GPS, GLONASS, BeiDou, Galileo, QZSS), Dual SIM, RS232/RS485 และ Geofencing เหมาะสำหรับงาน Fleet Management, Asset Tracking, Vehicle Monitoring และ Location-Based Services พร้อมระบบปฏิบัติการ RutOS

🛰️ จุดเด่นและการใช้งาน

🚚 Fleet Management & Tracking • 📍 Asset Location Monitoring • 🚗 Vehicle Telematics • 🛰️ GNSS/GPS Applications • 📡 Remote Site Connectivity • 🔒 Geofencing & Alerts • 🏭 Industrial IoT with Location Data

📹 วิดีโอแนะนำผลิตภัณฑ์

📦 HARDWARE

📡

Mobile Network

  • 4G LTE Cat 4 (150/50 Mbps)
  • 3G UMTS/HSPA+ (42/5.76 Mbps)
  • 2G GSM/GPRS (296/236.8 Kbps)
  • 1x SMA Mobile Antenna
  • Dual SIM (2x Mini 2FF)
🛰️

GNSS Features

  • GPS, GLONASS, BeiDou
  • Galileo, QZSS Support
  • 1x SMA GNSS Antenna
  • Coordinates & NMEA
  • NTRIP & Geofencing
⚙️

Processor & Memory

  • CPU: Mediatek MIPS 24KEc
  • ความเร็ว: 580 MHz
  • Storage: 128 MB
  • Memory: 16 MB
🔌

Serial & I/O

  • 1x RS232 Interface
  • 1x RS485 Interface
  • 3x Digital I/O (Configurable)
  • 16-pin Terminal Block
🌐

Ethernet

  • 1x RJ45 Port
  • 10/100 Mbps
  • Fast Ethernet
🔋

Physical Specs

  • ขนาด: 83 x 25 x 74.2 mm
  • น้ำหนัก: 165 g
  • Housing: Aluminum
  • อุณหภูมิ: -40°C ถึง +75°C
  • Power: 16-pin, 9-30 VDC

Hardware Specifications

Component Specification
Mobile 4G (LTE) – LTE Cat 4 150 Mbps DL, 50Mbps UL; 3G - 42 Mbps DL, 5.76 Mbps UL; 2G - 296 Kbps DL, 236.8 Kbps UL
CPU Mediatek, 580 MHz, MIPS 24KEc
Storage 128 MB
Memory 16 MB
Powering options 16-pin terminal, 9-30 VDC
SIM 2 x SIM slots (Mini SIM - 2FF), 1.8 V/3 V, double stacked SIM tray
Antenna connectors 1 x SMA connector for Mobile, 1 x SMA connector for GNSS
Ethernet 1 x RJ45 port, 10/100 Mbps
GNSS GPS, GLONASS, BeiDou, Galileo and QZSS
Inputs/Outputs 3 x Configurable digital I/O in 16-pin terminal block
Serial 1 x RS232, 1 x RS485
Status LEDs 3 x connection status LEDs, 3 x connection strength LEDs, 1 x power LED, 1 x ETH port status LED
Operating temperature -40 °C to 75 °C
Housing Aluminium housing
Dimensions (W x H x D) 83 x 25 x 74.2 mm
Weight 165 g

💻 SOFTWARE

Operating System

Operating system RutOS (OpenWrt based Linux OS)

Mobile Features

Mobile features Auto APN, Band lock, SIM switch, Operator black/white list, Data/SMS limits, Bridge, Passthrough

Network Features

Network features Routing, Network protocols, VoIP passthrough support, Connection monitoring, Firewall, Firewall status page, Ports management, Network topology, Hotspot, DHCP, QoS / Smart Queue Management (SQM), DDNS, Network backup, SSHFS

Monitoring & Management

Monitoring and Management WEB UI, FOTA, SSH, SMS, Call, TR-069, MQTT, SNMP, JSON-RPC, RMS

VPN & Tunneling

VPN and tunneling OpenVPN, IPsec, GRE, PPTP, L2TP, Stunnel, DMVPN, SSTP, ZeroTier, WireGuard, Tinc

Cloud Solutions

Cloud solutions RMS, FOTA, Azure IoT Hub, Cloud of Things, Cumulocity, ThingWorx

Hotspot Features

Hotspot Captive portal (Hotspot), internal/external Radius server, SMS authorization, internal/external landing page, walled garden, user scripts, URL parameters, user groups, individual user or group limitations, user management, 9 default customizable themes

GNSS Features

GNSS GNSS, Coordinates, NMEA, NTRIP, Server software, Geofencing
GNSS Systems GPS, GLONASS, BeiDou, Galileo and QZSS

อ่าน มากกว่า
