TRB247

คำอธิบาย

Teltonika TRB247 LTE Cat 1 + Dual SIM

Industrial LTE Cat 1 Gateway with RS232/RS485 & GNSS

TRB247 เป็น Industrial LTE Cat 1 Gateway รองรับความเร็วสูงสุด 10 Mbps DL / 5 Mbps UL พร้อม Dual SIM, RS232/RS485 Serial, GNSS (GPS/GLONASS/BeiDou/Galileo), 3x Digital Input/Output และ Ethernet 10/100 Mbps เหมาะสำหรับ Industrial IoT, Remote Monitoring, Asset Tracking และ M2M Applications พร้อมระบบปฏิบัติการ RutOS

🚀 จุดเด่นและการใช้งาน

🏭 Industrial Automation & Control • 📍 Asset Tracking & Fleet Management • 🔌 Remote Device Monitoring • 🚗 Vehicle Telematics • 📊 SCADA Systems • ⚡ Energy Management • 🏗️ Construction Site Monitoring • 🌾 Smart Agriculture • 📡 M2M Communications

📹 วิดีโอแนะนำผลิตภัณฑ์

📦 HARDWARE

📡

4G LTE Network

  • LTE Cat 1 bis
  • Download: 10 Mbps
  • Upload: 5 Mbps
  • Dual SIM (Mini 2FF)
  • 1x SMA LTE Antenna
⚙️

Processor & Memory

  • CPU: Mediatek MIPS 24KEc
  • ความเร็ว: 580 MHz
  • RAM: 128 MB DDR2
  • Storage: 16 MB SPI Flash
🌐

Ethernet & Network

  • 1x RJ45 Ethernet Port
  • 10/100 Mbps
  • Fast Ethernet
  • Auto MDI/MDIX
🛰️

GNSS Positioning

  • GPS Support
  • GLONASS Support
  • BeiDou Support
  • Galileo & QZSS
  • 1x SMA GNSS Antenna
🔌

Serial & I/O

  • RS232 Serial Port
  • RS485 Serial Port
  • 3x Digital Input (0-30V)
  • 3x Digital Output (30V/300mA)
  • 16-pin Terminal Block
🏭

Physical Specs

  • ขนาด: 83 x 25 x 82.6 mm
  • น้ำหนัก: 181 g
  • Housing: Anodized Aluminum
  • อุณหภูมิ: -40°C ถึง +75°C
  • Power: 9-30 VDC

Hardware Specifications

Component Specification
Mobile 4G LTE Cat 1 bis up to 10 DL/5 UL Mbps
CPU Mediatek, 580 MHz, MIPS 24KEc
RAM 128 MB, DDR2
Storage 16 MB, SPI Flash
Powering options 2-pin in 16-pin industrial terminal block, 9 - 30 VDC
SIM 2 x SIM slots (Mini SIM – 2FF), 1.8 V/3 V, double stacked SIM tray
Antenna connectors 1 x SMA connector for LTE, 1 x SMA connector for GNSS
Ethernet 1 x RJ45 ports, 10/100 Mbps
GNSS GPS, GLONASS, BeiDou, Galileo and QZSS
Inputs/Outputs 3 x Digital Input, 0 - 6 V detected as logic low, 8 - 30 V detected as logic high, 3 x Digital Output, Open collector output, max output 30 V, 300 mA
Serial RS232, RS485
Status LEDs 1 x connection status LED, 3 x connection strength LEDs, 1 x power LED, 1 x Eth port status LED
Operating temperature -40 °C to 75 °C
Housing Anodized aluminum housing and panels
Dimensions (W x H x D) 83 x 25 x 82.6 mm
Weight 181 g

💻 SOFTWARE

Operating System

Operating system RutOS (OpenWrt based Linux OS)

Mobile Features

Mobile features SIM switch, Status, SMS, USSD, Black/White list, Multiple PDN, Band management, SIM idle protection service, SIM PIN code management, APN, Bridge, Passthrough, Framed routing

Network Features

Network features VoIP passthrough support, Connection monitoring, Firewall, Firewall status page, Ports management, Network topology, Hotspot, DHCP, QoS / Smart Queue Management (SQM), DNS over HTTPS, DDNS, Network backup, Load balancing, SSHFS, VRF support, Traffic Management, Port Mirroring

Security Features

Security Authentication, Firewall, Attack prevention, VLAN, Mobile quota control, WEB filter, Access control, SSL certificate generation, 802.1x

VPN & Tunneling

VPN and tunneling OpenVPN, OpenVPN Encryption, IPsec, GRE, PPTP, L2TP, Stunnel, DMVPN, SSTP, ZeroTier, WireGuard, Tinc, Tailscale

Monitoring & Management

Monitoring and Management WEB UI, FOTA, SSH, SMS, Call, Email, TR-069, MQTT, SNMP, JSON-RPC, RMS

Cloud Solutions

Cloud solutions RMS, ThingWorx, Cumulocity - Cloud of Things, Azure IoT Hub

Industrial Services

Services BacNET, OPC UA, Modbus, Data to Server, Modbus MQTT GATEWAY, DNP3, DLMS

Location Tracking

Location Tracking GNSS, Coordinates, NMEA, NTRIP, Server software, Geofencing

อ่าน มากกว่า

TRB247

รูปแบบสินค้า

Teltonika TRB247 LTE Cat 1 + Dual SIM Industrial LTE Cat 1 Gateway with RS232/RS485 & GNSS TRB247 เป็น Industrial... อ่านเพิ่มเติม

0.00 ฿

      คำอธิบาย

      Teltonika TRB247 LTE Cat 1 + Dual SIM

      Industrial LTE Cat 1 Gateway with RS232/RS485 & GNSS

      TRB247 เป็น Industrial LTE Cat 1 Gateway รองรับความเร็วสูงสุด 10 Mbps DL / 5 Mbps UL พร้อม Dual SIM, RS232/RS485 Serial, GNSS (GPS/GLONASS/BeiDou/Galileo), 3x Digital Input/Output และ Ethernet 10/100 Mbps เหมาะสำหรับ Industrial IoT, Remote Monitoring, Asset Tracking และ M2M Applications พร้อมระบบปฏิบัติการ RutOS

      🚀 จุดเด่นและการใช้งาน

      🏭 Industrial Automation & Control • 📍 Asset Tracking & Fleet Management • 🔌 Remote Device Monitoring • 🚗 Vehicle Telematics • 📊 SCADA Systems • ⚡ Energy Management • 🏗️ Construction Site Monitoring • 🌾 Smart Agriculture • 📡 M2M Communications

      📹 วิดีโอแนะนำผลิตภัณฑ์

      📦 HARDWARE

      📡

      4G LTE Network

      • LTE Cat 1 bis
      • Download: 10 Mbps
      • Upload: 5 Mbps
      • Dual SIM (Mini 2FF)
      • 1x SMA LTE Antenna
      ⚙️

      Processor & Memory

      • CPU: Mediatek MIPS 24KEc
      • ความเร็ว: 580 MHz
      • RAM: 128 MB DDR2
      • Storage: 16 MB SPI Flash
      🌐

      Ethernet & Network

      • 1x RJ45 Ethernet Port
      • 10/100 Mbps
      • Fast Ethernet
      • Auto MDI/MDIX
      🛰️

      GNSS Positioning

      • GPS Support
      • GLONASS Support
      • BeiDou Support
      • Galileo & QZSS
      • 1x SMA GNSS Antenna
      🔌

      Serial & I/O

      • RS232 Serial Port
      • RS485 Serial Port
      • 3x Digital Input (0-30V)
      • 3x Digital Output (30V/300mA)
      • 16-pin Terminal Block
      🏭

      Physical Specs

      • ขนาด: 83 x 25 x 82.6 mm
      • น้ำหนัก: 181 g
      • Housing: Anodized Aluminum
      • อุณหภูมิ: -40°C ถึง +75°C
      • Power: 9-30 VDC

      Hardware Specifications

      Component Specification
      Mobile 4G LTE Cat 1 bis up to 10 DL/5 UL Mbps
      CPU Mediatek, 580 MHz, MIPS 24KEc
      RAM 128 MB, DDR2
      Storage 16 MB, SPI Flash
      Powering options 2-pin in 16-pin industrial terminal block, 9 - 30 VDC
      SIM 2 x SIM slots (Mini SIM – 2FF), 1.8 V/3 V, double stacked SIM tray
      Antenna connectors 1 x SMA connector for LTE, 1 x SMA connector for GNSS
      Ethernet 1 x RJ45 ports, 10/100 Mbps
      GNSS GPS, GLONASS, BeiDou, Galileo and QZSS
      Inputs/Outputs 3 x Digital Input, 0 - 6 V detected as logic low, 8 - 30 V detected as logic high, 3 x Digital Output, Open collector output, max output 30 V, 300 mA
      Serial RS232, RS485
      Status LEDs 1 x connection status LED, 3 x connection strength LEDs, 1 x power LED, 1 x Eth port status LED
      Operating temperature -40 °C to 75 °C
      Housing Anodized aluminum housing and panels
      Dimensions (W x H x D) 83 x 25 x 82.6 mm
      Weight 181 g

      💻 SOFTWARE

      Operating System

      Operating system RutOS (OpenWrt based Linux OS)

      Mobile Features

      Mobile features SIM switch, Status, SMS, USSD, Black/White list, Multiple PDN, Band management, SIM idle protection service, SIM PIN code management, APN, Bridge, Passthrough, Framed routing

      Network Features

      Network features VoIP passthrough support, Connection monitoring, Firewall, Firewall status page, Ports management, Network topology, Hotspot, DHCP, QoS / Smart Queue Management (SQM), DNS over HTTPS, DDNS, Network backup, Load balancing, SSHFS, VRF support, Traffic Management, Port Mirroring

      Security Features

      Security Authentication, Firewall, Attack prevention, VLAN, Mobile quota control, WEB filter, Access control, SSL certificate generation, 802.1x

      VPN & Tunneling

      VPN and tunneling OpenVPN, OpenVPN Encryption, IPsec, GRE, PPTP, L2TP, Stunnel, DMVPN, SSTP, ZeroTier, WireGuard, Tinc, Tailscale

      Monitoring & Management

      Monitoring and Management WEB UI, FOTA, SSH, SMS, Call, Email, TR-069, MQTT, SNMP, JSON-RPC, RMS

      Cloud Solutions

      Cloud solutions RMS, ThingWorx, Cumulocity - Cloud of Things, Azure IoT Hub

      Industrial Services

      Services BacNET, OPC UA, Modbus, Data to Server, Modbus MQTT GATEWAY, DNP3, DLMS

      Location Tracking

      Location Tracking GNSS, Coordinates, NMEA, NTRIP, Server software, Geofencing

      อ่าน มากกว่า
